Select  Part Number to View & Order Online

Brake Actuation Systems - Electric Brake Control

Prodigy® P2 Electronic Brake Control, for 1 to 4 Axle Trailers, Proportional

Prodigy® P2 Electronic Brake Control, for 1 to 4 Axle Trailers, Proportional
Click to enlarge image(s)
Features & Benifits
•Reverse battery protection for both vehicle and breakaway systems
•Designed to work with electric over hydraulic trailer drum and disc brakes
•Multiple mounting options –including 360 degree vertical rotation
•No level adjustment necessary –it adjusts itself to varying terrain as you drive
•Great for backing into tough spots! Works proportionally in reverse –with the ability to disable when not needed
•Produces stops that are in proportion to vehicle’s deceleration rate
•“Boost” feature gives users the ability to apply more initial trailer braking power
•Limited lifetime warranty (some conditions apply)

3" X 4.38" X 10.63"

Tekonsha P3 90195 P3® Brake Controller

Tekonsha P3 90195 P3® Brake Controller
Click to enlarge image(s)
Tekonsha P3 90195 - a breakthrough among proportional brake controls, offering a system that’s smooth and proportional with a multi-functioning LCD display featuring the most advanced easy-to-use diagnostics. Consumer preference drove the innovations that are incorporated into P3 including the capability of switching between an electric brake system or a hydraulic brake system. P3’s convenient features include a dash-hugging design, unique easy-to-use clip-mounting system, quick disconnect for a safe storage when not in use and the original “boost” feature that allows the driver to increase the initial power delivered to the trailer brakes. Including a range of diagnostic features, a pre-assembled wiring harness and a limited lifetime warranty, the P3 is for 2, 4, 6 and 8 brake trailers.

* Spec and Features

Distinct, easy to see LCD display with multiple color and contrast options
User can customize to choose English, French or Spanish display
Allows the user to switch between Electric and Electric Over Hydraulic trailer brakes
Highly advanced, easy-to-understand, roadside diagnostics
Easy access, "Up-Front" controls
Tekonsha's original "Boost" feature allows for different levels of customized braking
Compact, dash-hugging design
Unique, easy-to-use, clip-mounting system
Quick disconnect for easy storage; convenient storage pouch included
Covered by a Limited Lifetime Warranty

Electric Brake Controller

The Voyager incorporates Tekonsha’s patented sensor and is the best value you’ll find for smooth and secure trailer braking.  It’s compact size and features, like bi-colored LED brake monitor (to assure braking power being applied) make the Voyager extremely versatile.  Voyager minimizes interference with tow vehicle electrical system, uses a four wire hook up, has a broad setting range and is compatible with most vehicles.  The Voyager is covered by a 5-year “No-Fault” limited warranty from the date of consumer purchase.

Part # Description
6500017 Tekonsha Voyager 9030 (2-8 brakes)

The POD® (Power On Demand) is your best choice for 1 or 2 axle brake systems...especially when your installation options are limited. The POD® can be mounted in any direction, and its unique design features "up-front-easy-access" adjustment controls, even when mounted upside down. The POD® is the perfect choice for SUV's with almost vertical dash mounting surfaces.
POD® Features:

  • Solid state electronics
  • Power-on LED for a positive tow vehicle-to-trailer connection
  • "Up-front" manual over-ride controls
  • Rugged, easy mount chassis
  • Mounting hardware included
  • Smooth and simple installation
  • 3 year warranty

Part # Description
6500001 Tekonsha Pod Brake Control (2-4 brakes)

Standard Features

  • 100% solid state design
  • Standard 4-wire hook-up
  • 2-4 Brakes

Advanced Features

  • Digital LED that displays voltage output and assists  with leveling set-up
  • Power window that provides a numeric visual indication of the gain setting
  • Versatile mounting range of - 35 to 90 degrees
  • Independent manual slide that overrides the gain setting for full braking power
  • Exceeds NHTSA regulations by illuminating the trailer’s brake lights when the  manual slide is used
  • Short circuit protection that prevents damage to the controller and tow vehicle
  • 7-YEAR limited warranty
  • Manual override that provides braking power at whichever setting is greater (gain  or manual) instead of first dropping to zero output
Part # Description
20-115 Dexter Predator Brake Control (2-4 Brakes)
