For Dexter 3,500 lb. axles. For one brake.
Details:
Caution:
Can only be used with 14" and 15" wheels on a 5 on 4.50" bolt circle. Axle overhang requirement: Leaf spring axle = 7.50" per side. Torflex axle = 6.52" per side. A retrofit application will increase the current distance from outside of tire to outside of opposite tire 1". Make sure this will not cause any clearance issues.
* (4) Hex Nut (006-017-00)
* (1) 5-4.50 Hub (008-248-22)
* (1) Seal (010-019-00)
* (1) Grease Cap (021-041-02)
* (1) Bearing Cone (031-031-02)
* (1) Bearing Cone (031-033-02)
* (1) Rubber Plug (085-001-00)
* (1) Yoke Assembly (090-004-01)
* (1) Caliper Kit - LH (K71-624-00)
* (1) Rotor Kit (K71-626-00)
* (1) Instruction Sheet (059-806-00)
 |
